EVI UPS PDU 2U with Breaker for 6-10kVA (EP-UPSP11-MBP)
Key Features
Brand:EVI
Designed for EVI 6–10kVA online rack mount UPS systems
Extends UPS backup runtime significantly
Rack-mount 19-inch cabinet design
Supports scalable battery expansion
Hot-swappable battery support
Suitable for server rooms and data centers
Reliable sealed lead-acid battery configuration
Flexible rack or tower installation
Durable enterprise-grade construction
Optimized charging and battery management
FAST DELIVERY
EVI UPS PDU 2U with Breaker for 6-10kVA (EP-UPSP11-MBP)
Comprehensive Product Overview
The EVI UPS PDU 2U with Breaker for 6-10kVA (Model: EP-UPSP11-MBP) is an enterprise-grade Maintenance Bypass Power Distribution Unit (PDU) engineered specifically for high-capacity 6000VA to 10000VA single-phase online uninterruptible power supplies. In mission-critical environments, electronic components must undergo routine health checks, battery replacements, or hardware upgrades. This specialized 2U rack-mount bypass module provides a continuous hardware bridge that allows IT technicians to manually isolate the primary UPS system without interrupting electrical service to downstream servers, switches, and storage mainframes.
The system features an integrated, heavy-duty mechanical bypass rotary switch paired with a dedicated circuit breaker mechanism. By switching the unit from ‘Normal’ to ‘Bypass’ mode, utility power is safely routed around the UPS directly to the connected infrastructure. This enables hot-swapping or complete replacement of 6kVA and 10kVA power modules while keeping the active server load live. It functions as an absolute operational safeguard, eliminating the risk of accidental server drops or costly human-error reboots during emergency maintenance windows.
Housed in a rugged, space-saving 2U steel chassis, the EP-UPSP11-MBP is built to fit cleanly into standard 19-inch enterprise server enclosures. It features heavy-duty hardwired terminal blocks designed to handle the high amperage currents associated with 6kW and 10kW loads. This PDU effectively combines power distribution and maintenance bypass capabilities into a single consolidated unit, keeping rack layouts organized, maximizing space efficiency, and lowering infrastructure complexity.
Key Features
- Seamless Maintenance Bypass: Provides a manual rotary switch to safely route power around the UPS module, ensuring zero downtime for critical server loads during maintenance.
- Heavy-Duty Circuit Protection: Outfitted with a premium integrated breaker mechanism to prevent dangerous system overloads and short circuits.
- High Amperage Capability: Engineered specifically to manage the demanding electrical distribution requirements of 6kVA and 10kVA single-phase hardware networks.
- Space-Saving 2U Enclosure: Standard 19-inch rack-mount chassis slips neatly into any standard enclosure, optimizing valuable vertical rack space.
- Robust Steel Design: Fabricated from thick, high-grade structural metal to ensure long-term physical stability in busy, high-density server environments.
- Reliable Terminal Block Connectivity: Features secure input and output terminal blocks to guarantee dependable, low-resistance connections for heavy-gauge power wiring.
Technical Specifications
| System Feature | Specification Details |
|---|---|
| Model Designation | EP-UPSP11-MBP |
| Form Factor Dimension | 2U Rack-mount (Standard 19-inch width) |
| Compatible UPS Capacity | 6000VA / 6000W up to 10000VA / 10000W single-phase systems |
| Operational Modes | Normal (UPS Mode) and Bypass (Utility Mode) |
| Wiring Architecture | Hardwired Input and Output Terminal Blocks |
| Protection Profile | Integrated high-capacity circuit breaker switch |
| Chassis Material | Industrial heavy-gauge structural steel |
High-Utility Deployment Benefits
- Zero-Downtime Infrastructure: Allows technical personnel to update, repair, or completely replace a failed 6kVA/10kVA UPS asset without shutting down the datacenter network.
- Streamlined Rack Layout: Consolidates separate power routing lines, industrial breakers, and bypass panels into one efficient, professional rack-mounted unit.
- Foolproof Operational Safety: Designed with mechanical boundaries to prevent simultaneous connection errors, keeping your active server loads stable and protected.
Frequently Asked Questions
Can this maintenance bypass PDU be paired with line-interactive UPS units?
No. The EP-UPSP11-MBP is specifically mapped for high-capacity 6-10kVA online double-conversion single-phase UPS systems. It requires appropriate matching terminal block layouts to safely manage continuous industrial currents.
What is the difference between ‘Normal’ and ‘Bypass’ mode on this PDU?
In Normal mode, utility power passes through the PDU into the UPS where it is cleaned and backed up, then returns to the PDU to feed your servers. In Bypass mode, utility power is bridged directly to the servers inside the PDU, allowing you to unplug, service, or remove the UPS completely without dropping the network load.
Is this PDU a plug-and-play unit with standard wall plugs?
No. Because 6kVA and 10kVA systems manage very high power loads (up to 10,000 Watts), the inputs and outputs utilize heavy-duty hardwire terminal blocks. It must be installed by a qualified technician or electrical engineer in accordance with local power safety protocols.
