APC Smart-UPS SRT 5000VA 5kva 230V SRT5KXLI
Key Features
Brand: APC
5kVA / 5kW capacity for high-load applications
Double-conversion online UPS for clean and uninterrupted power
Rackmount/tower convertible design for flexible installation
Pure sine wave output for sensitive equipment
Intelligent battery management system for longer battery life
Scalable runtime with external battery packs
Built-in LCD display for real-time monitoring and configuration
Network management support for remote monitoring
Automatic bypass to maintain uptime during faults
FAST DELIVERY
APC Smart-UPS SRT 5000VA 230V (SRT5KXLI) Technical Guide
The APC Smart-UPS SRT 5000VA (SRT5KXLI) is an enterprise-class, high-density online double-conversion uninterruptible power supply (UPS) engineered to provide server-grade power protection for mission-critical server rooms, network closets, medical equipment, and distributed edge-computing hubs. Delivering 5000VA of clean capacity with a near-unity 0.9 power factor (4500 Watts / 4.5kW true power) in a versatile tower/rack convertible form factor, this premium online topology completely isolates sensitive network devices from grid instability. This comprehensive guide covers key product features, core technical specifications, and system setup instructions.
Premium Design and Key Features
Pure Online Double-Conversion Topology
The core power management system operates on continuous online double-conversion mechanics. Because the internal inverter circuit continuously feeds critical outbound server loads directly from the internal DC battery bus, the physical transfer time during a grid blackout is exactly 0 milliseconds. This zero-latency switchover guarantees that enterprise storage arrays, cloud hypervisors, and core routing matrices never experience premature reboots or frame dropouts.
Graphical LCD Display Panel with Dynamic Navigation
An advanced, intuitive diagnostic liquid crystal display dashboard anchors the front bezel layout. The screen delivers real-time visibility into incoming utility voltage parameters, outbound load wattage percentages, actual battery runtime reserves, and power efficiency data. Color-coded text screens provide instant notifications for specific internal faults or maintenance requirements without requiring a localized console connection.
Embedded Network Management and Eco Mode Tuning
The SRT5KXLI features a built-in Network Management Card port alongside pre-installed cloud connectivity options. Network administrators can map the UPS directly onto local area networks via an RJ-45 cable to execute remote graceful server shutdown coordination scripts, track power quality metrics, and adjust automated Eco Mode efficiency settings (up to 98% operational efficiency) to minimize commercial electricity expenses.
Versatile Tower/Rack Convertible Chassis Form Factor
The industrial metal frame is uniquely engineered with a dual-orientation convertible configuration. Out of the box, it can be deployed as a vertical standalone Tower footprint beside an office workspace desk. Alternatively, using integrated rack ears and accessory rail kits, the chassis collapses smoothly into a standard 3U rackmount profile to fit seamlessly inside a conventional 19-inch equipment enclosure.
Technical Specifications
- Apparent Output Capacity: 5000 Volt-Amps (5kVA) Enterprise Floor
- Actual Real Output Power: 4500 Watts (4.5kW) Continuous True Power Capability
- Topology Sub-System: True Online Double-Conversion Digital Processing
- Output Waveform Geometry: Pure Sinusoidal Alternating Current Wave Output
- Output Voltage Matrix: Default 230V (supports 220V, 240V user-configurable scaling)
- Input Voltage Spectrum: Wide 160V to 275V full load range (100V to 275V line-derated range)
- Outbound Output Sockets: 6 x IEC 320 C13 outlets, 4 x IEC 320 C19 outlets
- Input Connection Hook: Hardwired Terminal Block Interface (3-wire Single Phase 1W+N+G)
- Battery Cells Chemistry: Hot-Swappable Sealed Lead-Acid (VRLA) Battery Pack Modules
- Dynamic Expansion Slots: Embedded Network Management Card slot (RJ-45 interface)
- Chassis Dimension Index: 432mm Width x 130mm Height (3U Rack) x 719mm Depth; Weight: 54.4 Kilograms
